Description
Compact in size, yet packed with various features, the HL103M is a powerful GPS tracker designed to handle industrial and commercial fleet applications ranging from rental agencies and public transportation to freight transport and beyond. The device also features an external buzzer/horn alarm that makes it easy to locate your car in case you can’t find it, further adding to the security of your fleet. In addition to these features, remote listen-in and the suite of event-triggered alerts will make the HL103M a valuable part of your fleet management strategy.
500 mb SIM Data Included. You can recharge as required from this site
Features
GPS & BDS & LBS Positioning
A synergy of multiple positioning systems ensures that locations are accurately displayed on the cloud platform.
Low Voltage Alert
You'll be alerted via SMS when the motorcycle battery voltage is lower than the threshold.
Remote Listen-In
Inconspicuous mic allows for remote audio monitoring of the environment around the device.
External Buzzer/Horn Supported
Warn the driver once the tracker detects speeding or fatigue driving, and it also supports audible/light warnings to search for vehicles.
Multiple Alerts
Instant alerts for atypical events such as abnormal vibration, speeding, geo-fence entry/exit, etc.
IP66 Dust & Water Resistance
Rugged design ensures continued optimal performance, even in the toughest conditions.
Specifications
GNSS
Positioning system |
GPS+BDS+LBS |
Positioning accuracy |
<2.5m CEP |
Tracking sensitivity |
-165dBm |
Acquisition sensitivity |
-148dBm
|
TTFF (open sky) |
Avg. hot start ≤1sec Avg. cold start ≤32sec
|
Cellular
Communication network |
LTE Cat 1/GSM
|
Frequency |
HL103M (L) LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 GSM: B2/B3/B5/B8VL103M (E) LTE-FDD: B1/B3/B7/B8/B20/B28 LTE-TDD: B34/B38/B39/B40/B41 GSM: B2/B3/B5/B8
|
Power
Battery |
270mAh/3.7V industrial-grade Li-Polymer battery |
Input voltage |
9-90VDC |
Interface
LED indication |
GNSS (Blue), Cellular (Yellow), Power (Red) |
SIM |
Micro-SIM |
Data storage |
16+16Mb
|
Digital inputs |
ACC, SOS |
Digital outputs |
Relay, IO for buzzer/horn output |
Physical specification
Dimensions |
92.0 x 40.0 x 20.0mm |
Weight |
55g |
Operating environment
Operating temperature |
–20℃ to +70℃ |
IP rating |
IP66 |
Feature
Sensors |
Accelerometer |
Scenarios |
Vehicle movement alert, Speeding alert, Geo-fence entry/exit, Vehicle battery detection, LTE jamming detection, GPS jamming detection |
* We reserve the right to the final interpretation of this page. All information is for reference only and is subject to change without further notice.
